Double shaft stepper motor, Small size, High torque, Low noise, 2 phase, 1.8°, NEMA11
● High Torque
● Long Life,Low Losses
● Small Size,High Efficiency
● Available options for Wire Harness, Flexible Coupling
Brand Name: MOONS'
Price: USD  45.61  EA
Shipping to:
Days to Ship: working days
Days to Ship: Contact
customer service
Free shipping to USA for orders of $100 or more
Add to compare
Payment Methods

Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Double
Frame Size NEMA11(28mm)
Length mm 51
Rated Current A 0.7
Holding Torque Nm 0.17
Resistance Ohms ±10%@20℃ 6.7
Inductance mH Typ. 6.8
Coil Type Bi-Polar
Detent Torque mNm 8
Rotor Inertia gcm² 18
Front Shaft Length mm 15
Front Shaft Diameter mm 5
Rear Shaft Length mm 13
Rear Shaft Diameter mm 5
Terminal Number 4
Connect Plug
Insulation Class B(130°C)
Approvals RoHS
IP Rating IP40
Weight kg 0.2
Recommended Options

Filter By Product Type

All Products
Flexible Coupling
Wire Harness
2D Drawings
Title Type Size(KB) Date View times Download
MS11HS Series Double Shaft _2D Drawings.pdf PDF 135 2017-10-30 9
