MS16HS0P4029

(Active)
Stepper motor, High torque, Big rotor, Smooth movement, 2 phase, 1.8°, NEMA16
● High Torque
● Long Life,Low Losses
● Small Size,High Efficiency
● Available options for Wire Harness, Flexible Coupling, Damper
Brand Name: MOONS'
Price: USD  38.65  EA
Quantity:
Shipping to:
Days to Ship: working days
Days to Ship: Contact customer service
Free shipping to USA for orders of $100 or more
Add to compare
Payment Methods

Certificates:
Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Single
Frame Size NEMA16(39mm)
Length mm 26
Rated Current A 0.29
Holding Torque Nm 0.2
Resistance Ohms ±10%@20℃ 40
Inductance mH Typ. 52
Coil Type Bi-Polar
Detent Torque mNm 8
Rotor Inertia gcm² 20
Front Shaft Length mm 24
Front Shaft Diameter mm 5
Terminal Number 4
Connect Plug
Insulation Class B(130°C)
Approvals RoHS
IP Rating IP40
Weight kg 0.15
Recommended Options

Filter By Product Type

All Products
Wire Harness
Damper
Flexible Coupling

Dimensions


■ Motor Dimensions: mm(in)

■ Mating connector With Leads(order separately) Dimensions: mm(in)
4Lead Part Number: 46341402028466Lead Part Number: 4634140204489

2D Drawings
Title Type Size(KB) Date View times Download
MS16HS Series_2D Drawings.pdf PDF 68 2016-12-21 8
3D Model
Title Type Size(KB) Date View times Download
MS16HS0P_3D Model.step STEP 1293 2017-01-10 2
Torque Speed Curves
Title Type Size(KB) Date View times Download
MS16HS Series_Torque Speed Curve.pdf PDF 6312 2016-12-21 10
Catalog
Title Type Size(KB) Date View times Download
HB_EN_Catalog20170829.pdf PDF 17808 2017-10-13 266
