MS17HD6P4150-M

(Active)
Stepper motor,Double Shaft, High torque, Low noise, Smooth movement, 2 phase, 1.8°, NEMA17
● High Torque
● Long Life, Low Losses
● Small Size, High Efficiency
● Available options for Wire Harness, Flexible Coupling, Damper
Brand Name: MOONS'
Price: USD  44.08  EA
Quantity:
Shipping to:
Days to Ship: working days
Days to Ship: Contact customer service
Free shipping to USA for orders of $100 or more
Add to compare
Payment Methods

Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Double
Frame Size NEMA17(42mm)
Length mm 48.3
Rated Current A 1.5
Holding Torque Nm 0.62
Resistance Ohms ±10%@20℃ 2.2
Inductance mH Typ. 4.9
Coil Type Bi-Polar
Detent Torque mNm 25
Rotor Inertia gcm² 82
Front Shaft Length mm 24
Front Shaft Diameter mm 5
Rear Shaft Length mm 13
Rear Shaft Diameter mm 5
Terminal Number 4
Connect Plug
Insulation Class B(130°C)
Approvals UL,RoHS
IP Rating IP40
Weight kg 0.36
Recommended Options

Filter By Product Type

All Products
Drives
Pulse & Direction Control
Wire Harness
Flexible Coupling
Damper

Dimensions


■ Motor Dimensions: mm(in)

■ Mating connector With Leads(order separately) Dimensions: mm(in)


2D Drawings
Title Type Size(KB) Date View times Download
MS17HD Series_2D Drawings.pdf PDF 111 2016-12-21 24
