PL34HD1L8350

(Active)
Stepper motor, Ultra high torque, High efficiency, High accuracy, 2 phase, 1.8°, NEMA40
● Ultra high torque
● High Efficency
● Low Inertia
● Quick Response
● Low Vibration
● Low Noise
Brand Name: MOONS'
Price: USD  282.35  EA
Quantity:
Shipping to:
Days to Ship: working days
Days to Ship: Contact customer service
Free shipping to USA for orders of $100 or more
Add to compare
Payment Methods

Certificates:
Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Single
Frame Size NEMA34(86mm)
Length mm 97
Rated Current A 7
Holding Torque Nm 9
Resistance Ohms ±10%@20℃ 0.34
Inductance mH Typ. 3.2
Coil Type Bi-Polar
Detent Torque mNm 225
Rotor Inertia gcm² 1570
Front Shaft Length mm 31.75
Front Shaft Diameter mm 12.7
Terminal Number 8
Connect L Parallel
Insulation Class B(130°C)
Approvals UL,RoHS
IP Rating IP40
Weight kg 2.7

Dimensions


■ Motor Dimensions: mm(in)


2D Drawings
Title Type Size(KB) Date View times Download
PL34HD Series_2D Drawings.pdf PDF 816 2016-12-21 6
3D Model
Title Type Size(KB) Date View times Download
PL34HD1L_3D Model.step STEP 812 2017-06-05 6
Torque Speed Curves
Title Type Size(KB) Date View times Download
PL34HD Series_Torque Speed Curve.pdf PDF 6448 2016-12-21 12
Catalog
Title Type Size(KB) Date View times Download
HB_EN_Catalog20170829.pdf PDF 17808 2017-10-13 305
