Stepper motor, Ultra high torque, High efficiency, High accuracy, 2 phase, 1.8°, NEMA34
● Ultra high torque
● High Efficency
● Low Inertia
● Quick Response
● Low Vibration
● Low Noise
Brand Name: MOONS'
Price: USD  360.0  EA
Shipping to:
Lead Time: working days
Lead Time: Contact
customer service

* Free shipping to North America and most of Europe for orders of $100 or more

Add to compare
Payment Methods

Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Single
Frame Size NEMA34(86mm)
Length mm 157
Rated Current A 10
Holding Torque Nm 15
Holding Torque oz-in 2124.3
Resistance Ohms ±10%@20℃ 0.23
Inductance mH Typ. 2.3
Coil Type Bi-Polar
Detent Torque mNm 375
Rotor Inertia gcm² 3110
Front Shaft Length mm 31.75
Front Shaft Diameter mm 15.875
Terminal Number 8
Connect L Parallel
Insulation Class B(130°C)
Certification UL,RoHS
IP Rating IP40
Weight kg 4.9
Click the curve symbol,
You can switch the display
  • Ambient temperature: 25℃.,Max temperature rise: 60℃.
  • Microstep: 200 steps/rev(1.8°step angle),400 steps/rev(0.9°step angle)
  • Details for temperature test,Details
  • Torque Optimization Configurator (Enter your voltage/current requirements to optimize the torque curve.)


    ■ Motor Dimensions: mm(in)

    2D Drawings
    Title Type Size(KB) Download
    PL34HD3L8500 2D.pdf PDF 187
    3D Model
    Title Type Size(KB) Download
    PL34HD3L_3D Model.step STEP 818
    Torque Speed Curves
    Title Type Size(KB) Download
    PL34HD Series_Torque Speed Curve.pdf PDF 6448
    Title Type Size(KB) Download
    Hybrid Stepper Motor_Catalog2019.pdf PDF 15487
