ML34HD3L8350

(Active)
Stepper motor, High torque, Low inertia, Fast raising speed, 2 phase, 1.8°, NEMA34
● Low Inertia
● Quick Response
● High Torque
● High Efficiency
● Low Vibration
● Low Noise
Brand Name: MOONS'
Price: USD  357.9  EA
Quantity:
Shipping to:
Days to Ship: working days
Days to Ship: Contact
customer service
Free shipping to USA for orders of $100 or more
Add to compare
Payment Methods

Certificates:
Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Single
Frame Size NEMA34(86mm)
Length mm 157
Rated Current A 7
Holding Torque Nm 11.9
Resistance Ohms ±10%@20℃ 0.46
Inductance mH Typ. 6.3
Coil Type Bi-Polar
Detent Torque mNm 250
Rotor Inertia gcm² 3100
Front Shaft Length mm 31.75
Front Shaft Diameter mm 12.7
Terminal Number 4
Connect Leads
Insulation Class B(130°C)
Approvals UL,RoHS
IP Rating IP40
Weight kg 4.9

Dimensions


■ Motor Dimensions: mm(in)

2D Drawings
Title Type Size(KB) Date View times Download
ML34HD Series_2D Drawings.pdf PDF 72 2016-12-21 10
3D Model
Title Type Size(KB) Date View times Download
ML34HD3L_3D Model.step STEP 818 2017-01-10 1
Torque Speed Curves
Title Type Size(KB) Date View times Download
ML34HD Series_Torque Speed Curve.pdf PDF 6443 2016-12-21 15
Catalog
Title Type Size(KB) Date View times Download
Hybrid Stepper Motor_Catalog20170829.pdf PDF 17808 2017-10-13 276
