Stepper motor, High torque, Low inertia, Fast raising speed, 2 phase, 1.8°, NEMA42
● Low Inertia
● Quick Response
● High Torque
● High Efficiency
● Low Vibration
● Low Noise
Brand Name: MOONS'
Price: USD  475.03  EA
Shipping to:
Days to Ship: working days
Days to Ship: Contact customer service
Free shipping to USA for orders of $100 or more
Add to compare
Payment Methods

Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Single
Frame Size NEMA42(110mm)
Length mm 202
Rated Current A 16
Holding Torque Nm 32
Resistance Ohms ±10%@20℃ 0.144
Inductance mH Typ. 3.2
Coil Type Bi-Polar
Detent Torque mNm 800
Rotor Inertia gcm² 16200
Front Shaft Length mm 55.6
Front Shaft Diameter mm 19.05
Terminal Number 8
Connect L Parallel
Insulation Class B(130°C)
Approvals UL,RoHS
IP Rating IP40
Weight kg 11.6


■ Motor Dimensions: mm(in)

2D Drawings
Title Type Size(KB) Date View times Download
ML42HS Series_2D Drawings.pdf PDF 598 2016-12-21 7
3D Model
Title Type Size(KB) Date View times Download
ML42HS3_3D Model.step STEP 1715 2017-06-19 5
Torque Speed Curves
Title Type Size(KB) Date View times Download
ML42HS Series_ Torque Speed Curve.pdf PDF 5237 2016-12-21 8
Title Type Size(KB) Date View times Download
HB_EN_Catalog20170829.pdf PDF 17808 2017-10-13 302
