MS24HS3P4150


Stepper motor, High torque, Low noise, Smooth movement, 2 phase, 1.8°, NEMA24
● High Torque
● High Efficiency
● Low Noise,Low Losses
● Available options for Wire Harness, Flexible Coupling
Brand Name: MOONS'
Price: USD  74.8  EA
Quantity:
Shipping to:
Days to Ship: working days
Days to Ship: Contact
customer service

* Free shipping to North America and Europe for orders of $100 or more

Add to compare
Payment Methods

Certificates:
Buyer Protection:
Free Exchange if the item has quality problems within 1 year. Learn more
Parameter Unit Value
Phase 2
Step Angle 1.8°
Shaft Single
Frame Size NEMA24(60mm)
Length mm 67
Rated Current A 1.5
Holding Torque Nm 2.4
Holding Torque oz-in 339.89
Resistance Ohms ±10%@20℃ 4.2
Inductance mH Typ. 12.1
Coil Type Bi-Polar
Detent Torque mNm 95
Rotor Inertia gcm² 560
Front Shaft Length mm 20.6
Front Shaft Diameter mm 6.35
Terminal Number 4
Connect Plug
Insulation Class B(130°C)
Approvals UL,RoHS
IP Rating IP40
Weight kg 1.05
Recommended Options

Filter By Product Type

All Products
Wire Harness
Drives
Pulse & Direction Control
Torque
TEMP RISE
MS24HS3P4150
  • Ambient temperature: 25℃.
    Max temperature rise: 60℃.
  • Details for temperature test.
    Details
  • Torque Optimization Configurator?(Enter your voltage/current requirements to optimize the torque curve.)

    Dimensions


    ■ Motor Dimensions: mm( in)

    ■ Mating connector With Leads(order separately) Part Number: 4634140201393 Dimensions: mm(in)



    2D Drawings
    Title Type Size(KB) Download
    MS24HS Series_2D Drawings.pdf PDF 75
    3D Model
    Title Type Size(KB) Download
    MS24HS3P_3D Model.step STEP 858
    Torque Speed Curves
    Title Type Size(KB) Download
    MS24HS Series_Torque Speed Curve.pdf PDF 5832
